Hitachi

Wheel Loader

ZW160PL-7

Request a Quote

When your job demands both performance and precision, the Hitachi ZW160PL-7 Wheel Loader stands ready to deliver.  This machine is built to handle a variety of tasks, from construction and landscaping to agriculture and municipal work.  PL configurations offer purpose-built arms with longer reach and parallel lift linkage for ideal performance in material handling and fork applications.

Discuss the specifications of this model and how it compares to your needs with the expert team at Wajax.

Product Highlights

  • Robust Engine Performance: Features a Cummins B4.5 turbocharged diesel engine with 169Hp, a 15% increase over the previous model. Meets EPA Tier 4 Final EU Stage V emissions standard with no EGR technology.
  • Advanced Hydraulic System: Standard third function hydraulics with integrated proportional control and detent function provide next level performance.
  • Operator Comfort & Safety: The redesigned ROPS / FOPS certified cab provides reduced noise pollution, standard high back, heated air suspension seat, and Bluetooth connectivity. Enhanced safety with rear obstacle detection with brake assist, and standard 270-degree areal angle camera system.
  • Efficient Power Train & Braking System: Features electronically controlled hydrostatic transmission with adjustable breaking performance, selectable on-board traction control mode, and standard limited slip front and rear differentials.
  • Durable Design & Build: Built for durability with heavy duty structures and high performance, thermostatically controlled cooling system designed to withstand Canada’s challenging conditions.
  • Intuitive Controls & Technology: Equipped with all new seat integrated electric over hydraulic controls, and updated easy to navigate main and pillar mounted sub monitor.

Specifications

Engine Output Max Gross 126 kW (169 hp)
Engine Output Max Net 124 kW (166 hp) at 2000 rpm (ISO 9249:2007 net)
Bucket Capacity Ranges from 2.0 m³ (2.6 yd³) to 3.6 m³ (4.7 yd³) depending on the bucket type
Operating Weight Between 12,910 kg (28,467 lbs) and 13,600 kg (29,983 lbs)
Engine model CUMMINS B4.5
Breakout force (standard arm) 10,690 kgf (23,567 lbf)
